Growatt 50kW OnGrid Inverter

Specifications

• Brand: Growatt
• Model: MAX 50KTL3-X LV
• Inverter Type: On-Grid (Three-Phase)
• Rated AC Output Power: 50,000W
• Max DC Input Voltage: 1100V
• Start-Up Voltage: 200V
• MPPTs: 4 (Independent Maximum Power Point Trackers)
• Max Efficiency: 98.8%
• Euro Efficiency: ~98.4%
• Max PV Input Current: 30A per MPPT
• Max Short Circuit Current: 40A per MPPT
• AC Output Voltage: 400V, Three-Phase
• Frequency: 50Hz / 60Hz
• Cooling Method: Smart Intelligent Cooling
• Protection Features: DC/AC Surge Protection, Anti-PID, Overvoltage, Overcurrent, Islanding Protection
• Communication Ports: RS485, WiFi / GPRS (optional), PLC
• Protection Rating: IP65 (Dustproof & Waterproof)
• Operating Temperature Range: -30°C to +60°C
• Dimensions: ~700 × 480 × 250 mm
• Weight: ~70 kg
• Warranty: 5 Years Standard (Extendable)
