SOFAR Hybrid

SOFAR Hybrid Inverter Price in Pakistan

SOFAR hybrid inverters combine solar generation, battery charging, grid interaction and backup power management in one unit. Hajvery Solar currently offers 6kW, 8kW and 10kW SOFAR single-phase hybrid inverters for Pakistani homes and other suitable solar installations.

The SOFAR hybrid inverter price in Pakistan varies according to inverter capacity, stock availability, exchange rate and included warranty coverage. Check the current prices shown with the products or contact Hajvery Solar for an updated quotation.

Compare SOFAR 6kW, 8kW and 10kW Hybrid Inverters

SOFAR HYD-6K-LS1 6kW Hybrid Inverter

The 6kW model supports a recommended maximum PV array of 12kWp. It offers a maximum charging current of 175A and a maximum discharging current of 150A. This model is suitable for properly sized residential solar systems requiring battery storage and essential-load backup.

SOFAR HYD-8K-LS1 8kW Hybrid Inverter

The 8kW model supports a recommended maximum PV array of 16kWp. Its maximum charging and discharging current is 190A. It provides greater output and battery-handling capacity for larger residential systems and higher daytime or backup loads.

SOFAR HYD-10K-LS1 10kW Hybrid Inverter

The 10kW model supports a recommended maximum PV array of 20kWp and provides up to 210A charging and discharging current. It also features four PV string inputs across two MPPT trackers and integrated AFCI protection. This model is intended for systems with higher solar generation and backup power requirements.

Fast Backup and Overload Support

The available SOFAR models automatically switch between grid and backup operation in approximately 4ms. This rapid transfer helps maintain power to selected backup circuits during a grid failure.

They also support backup overload of up to 200% of rated output for 10 seconds. This capability can help with short starting surges, although the connected loads and backup circuits must still be designed according to the inverter’s rated and peak output limits.

Dual MPPT Solar Management

Each model includes two independent MPPT trackers. Dual MPPT technology allows separate solar-panel strings to be managed more effectively, especially when panels have different orientations or operating conditions.

The 6kW, 8kW and 10kW models provide maximum efficiency of up to 97.6% and MPPT efficiency of up to 99.9%. Actual system performance will depend on solar-panel configuration, temperature, shading, wiring and installation quality.

Low-Voltage Battery Compatibility

These SOFAR hybrid inverters operate with a 40–60V low-voltage battery system. They support compatible lithium-ion and lead-acid batteries, with RS485 or CAN communication available for battery-management systems.

Battery compatibility should be confirmed before purchase. A battery should not be connected only because its nominal voltage falls within the inverter’s operating range. The battery model, BMS communication protocol, current capability and SOFAR compatibility requirements must also be checked.

IP66 Protection and Smart Monitoring

IP66 protection helps protect the inverter enclosure against dust and powerful water jets. The inverters also include an LCD interface and app-based monitoring. Optional Wi-Fi, 4G or LAN connectivity may be used for remote performance monitoring, depending on the installed communication accessory.

The available models support diesel-generator integration and parallel inverter operation, giving qualified system designers additional flexibility when planning larger or more advanced backup systems.

Which SOFAR Hybrid Inverter Should You Choose?

Choose an inverter after evaluating your simultaneous load, appliance starting load, solar-array capacity, battery size and desired backup time.

• Consider 6kW for moderate residential loads and a correctly sized battery system.
• Consider 8kW where greater daytime usage or backup capacity is required.
• Consider 10kW for larger single-phase systems with higher solar and battery power requirements.

A detailed load assessment is recommended before making the final selection.

Official 10-Year Replacement Warranty

The SOFAR 6kW, 8kW and 10kW hybrid inverters listed by Hajvery Solar include an official 10-year replacement warranty. Confirm warranty activation, installation conditions, documentation requirements and the applicable claim procedure when placing your order.

Frequently Asked Questions

Which SOFAR hybrid inverter models are currently available?

The current range includes SOFAR HYD-6K-LS1 6kW, HYD-8K-LS1 8kW and HYD-10K-LS1 10kW hybrid inverters.

Are these SOFAR hybrid inverters single phase?

Yes. All three models listed in this category are single-phase hybrid inverters.

Which battery voltage do these inverters support?

They support a low-voltage battery operating range of 40–60V. Battery and BMS compatibility must be confirmed for the exact battery model.

Can a SOFAR hybrid inverter provide backup during load shedding?

Yes. When installed with a suitable battery and correctly configured backup circuits, the inverter can supply selected loads during a grid outage.

What is the SOFAR hybrid inverter warranty?

The listed models come with an official 10-year replacement warranty. Applicable conditions and the claim process should be confirmed at the time of purchase.
