Technical Specifications

Physical Characteristics

• Dimensions (H × W × D): 595 × 420 × 160 mm

• Weight: 47 kg

• Installation: Floor-stand / Wall-mounted

Electrical Characteristics

• Battery type: Lithium LFP (LiFePO₄)

• Nominal energy (capacity): 5.12 kWh

• Nominal voltage: 51.2 V

• Usable voltage range: 48 – 57.6 V

• Max charge current: 75 A

• Discharge current: 100 A

• Depth of Discharge (DoD): 90%

• Internal resistance: ≤ 40 (as listed)

• Round-trip efficiency: > 95%

• DC disconnect: MOSFET FUSE

BMS & Monitoring

• Power consumption: < 3 W (work), < 100 mW (sleep)

• Monitoring parameters: System voltage, system current, cell voltage, cell temperature

• Communication: CAN, Wi-Fi, RS485

Operating Conditions

• Operating temperature: -10°C to 50°C

• Recommended operating temperature: 15°C to 30°C

• Recommended storage temperature: 15°C to 30°C

• Humidity: 5% to 95%

• Max altitude: 2000 m

• Cooling strategy: Natural convection

Reliability & Certifications

• Hazardous materials classification: Class 9

• Transportation: UN38.3

• Ingress protection (IP): IP20

• System configuration: 1 to 16 in parallel

Warranty

• Product & performance warranty: 7 years
